Product Name:
K37 Helical gear reducer K37 gearbox and K37 gear motor
Model No.:
K37

Product Abstract:

K37 Helical gear reducer K37 gearbox and K37 gear motor Rated motor power: 0.18kW-3kW Speed ratio: 1:3-1:300

Product Description

Contact us for enquiry and ordering:

whatsapp:+8613760859053

https://wa.me/8613760859053

email: sales@yygear.com

K37 Helical gear reducer K37 gearbox and K37 gear motor

Speed ratio: 1:3-1:300

Customise in color,nameplate,packing.

k37 series helical gear reducer has the characteristics of strong versatility, good combination and strong carrying capacity. It has the advantages of easy transmission ratio, high efficiency, small vibration and large radial load of shaft. This series not only can be combined with various reducers and transmissions to meet the requirements, but also facilitates the localization of related transmission equipment.

product description

feature

High modular design.

The integral casting shell has compact size, high load carrying capacity, stable transmission and low noise.

Good anti-leakage performance, good sealing, can be widely used in industrial production.

Energy efficient.

Cost savings and low maintenance costs.

Main application industries

Cement machinery, environmental protection machinery, electronic appliances, road construction machinery,

Building materials machinery, rubber machinery, petroleum machinery and other industries

Technical data
Shell material	Cast iron / ductile iron
Shell hardness	HBS190-240
Gear material	20CrMnTi alloy steel
Gear surface hardness	HRC58 ° ~ 62 °
Gear core hardness	HRC33 ~ 40
Input / output shaft material	42CrMo alloy steel
Input / output shaft hardness	HRC25 ~ 30
Gear machining accuracy	Precision grinding, level 6 ~ 5
lubricating oil	GB L-CKC220-460, Shell withstand voltage 220-460
Heat treatment	Tempering, carburizing, quenching, etc.
effectiveness	94% ~ 96% (depending on the transmission stage)
Noise (maximum)	60 ~ 68dB
Temperature rise (MAX)	40 ° C
Temperature rise (oil) (maximum)	50 ° C
vibration	≤20µm
Recoil	≤20Arcmin

SIZE	Shaft Dia (mm)		Center Height	Output	Power(kw)	Ratio	Permissible	Weight
	Solid Hallow			Flange Dia.			Torque(N.m)	(KGS)
				(mm)
37	φ25k6	φ30h7	100	φ110/160	0.18-3.0	5.36-106.38	200	11
47	φ30k6	φ35h7	112	φ120/200	0.18-3.0	5.81-131.87	400	20
57	φ35k6	φ40h7	132	φ155/250	0.18-5.5	6.57-145.14	600	27
67	φ40k6	φ40h7	140	φ155/250	0.18-5.5	7.14-144.79	820	33
77	φ50k6	φ170	180	φ170/300	0.37-11.0	7.24-292.18	1550	57
87	φ60m6	φ60h7	212	φ215/350	0.75-22.0	7.19-197.18	2700	85
97	φ70m6	φ70h7	265	φ260/450	1.1-30.0	8.95-176.05	4300	130
107	φ90m6	φ90h7	315	φ304/450	3.0-45.0	8.74-141.46	8000	250
127	φ110m6	φ100h7	375	φ350/550	7.5-90.0	8.68-146.07	13000	380
157	φ120m6	φ120h7	450	φ400/660	11.0-160.0	12.65-150.41	18000	610
167	φ160m6	φ140h7	500	φ800	11.0-200.0	17.28-163.91	32000	1015
187	φ190m6	φ160h7	600	φ800	18.5-200.0	17.27-180.78	50000	1700

K series reducer has the following models:

K37,K47,K57,K67,K77,K87,K97,K107,K127,K157,K167,K187

KA37 KA47 KA57 KA67 KA77 KA87 KA97 KA107 KA127 KA157 KA167 KA187

KF37 KF47 KF57 KF67 KF77 KF87 KF97 KF107 KF127 KF157 KF167 KF187

KAF37 KAF47 KAF57 KAF67 KAF77 KAF87 KAF97 KAF107 KAF127 KAF157 KAF167 KAF187

KAZ37 KAZ47 KAZ57 KAZ67 KAZ77 KAZ87 KAZ97 KAZ107 KAZ127 KAZ157 KAZ167 KAZ187

KAT37 KAT47 KAT57 KAT67 KAT77 KAT87 KAT97 KAT107 KAT127 KAT157 KAT167 KAT187

KAB37 KAB47 KAB57 KAB67 KAB77 KAB87 KAB97 KAB107 KAB127 KAB157 KAB167 KAB187

K37,K47,K57,K67,K77,K87,K97,K107,K127,K157,K167,K187

K37 K47 K57 K67 K77 K87 K97 K107 K127 K157 K167 K187

KA37 KA47 KA57 KA67 KA77 KA87 KA97 KA107 KA127 KA157 KA167 KA187

KF37 KF47 KF57 KF67 KF77 KF87 KF97 KF107 KF127 KF157 KF167 KF187

KAF37 KAF47 KAF57 KAF67 KAF77 KAF87 KAF97 KAF107 KAF127 KAF157 KAF167 KAF187

KAZ37 KAZ47 KAZ57 KAZ67 KAZ77 KAZ87 KAZ97 KAZ107 KAZ127 KAZ157 KAZ167 KAZ187

KAT37 KAT47 KAT57 KAT67 KAT77 KAT87 KAT97 KAT107 KAT127 KAT157 KAT167 KAT187

KAB37 KAB47 KAB57 KAB67 KAB77 KAB87 KAB97 KAB107 KAB127 KAB157 KAB167 KAB187
