Feature：

● Smooth running,low noise gear tooth needle more engagement.

● Cycloidal tooth profile provides a high contact ratio to withstand overload shocks

● Compact size: single ratio available from 1/9 to 1/87, double stage up from 1/99 to 1/7569

● Ideal for dynamic applications: frequent start-stop-reversing duties suits for cyclo speed reducer since inertia is low

● Reduce maintenance costs: high reliability, long life, minimal maintenance compared to conventional gearboxes

● Grease Lubricated & Oil Lubricated Models Available

● Output Shaft Rotation Direction: Single Reduction: Clockwise Rotation; Double Reduction→ Counter Clockwise Rotation

● Ambient Conditions: Indoor Installation:10-40 Celsius, Max 85% Humidity, Under 1000m Altitude, Well Ventilated Environment, Free of corrosive,explosive gases, vapors and dust

● Slow Speed Shaft Direction: Horizontal, Vertical Up & Down, Universal Direction

● Mounting Style: Foot Mount, Flange Mount & Vertical F-flange Mount,

● Input Connection: Cyclo Integral Motor, Hollow Input Shaft Adapter

● Coupling Method With Driven Machine: Coupling, Gears, Chain Sprocket Or Belt

● Cycloid reducer Capacity Range: 0.37kW ~ 11kW;
